CPU

- Supports Socket FM2+ 95W / FM2 100W processors

Chipset

- AMD A58 FCH (Bolton-D2)

Memory

Dual Channel DDR3 Memory Technology

- 2 x DDR3 DIMM Slots

- Supports DDR3 1866/1600/1333/1066 non-ECC, un-buffered memory

- Max. capacity of system memory: 32GB*

- Supports Intel® Extreme Memory Profile (XMP) 1.3 / 1.2

Supports AMD Memory Profile (AMP)

*Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation.

BIOS

- 64Mb AMI UEFI Legal BIOS with GUI support

- Supports "Plug and Play"

- ACPI 1.1 Compliant wake up events

Supports jumperfree

- SMBIOS 2.3.1 support

- DRAM, CPU Voltage multi-adjustment

Audio, Video and Networking

Graphics

Integrated AMD Radeon™ R7/R5 Series Graphics in A-Series APU

- DirectX 11.1, Pixel Shader 5.0 with FM2+ CPU. DirectX 11, Pixel Shader 5.0 with FM2 CPU.

- Max. shared memory 2GB

- Three graphics output options: D-Sub, DVI-D and HDMI

Supports Triple Monitor

- Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 24Hz * Only FM2+ APU can support up to 4096x2160 resolution display via HDMI port

- Supports Dual-link DVI-D with max. resolution up to 2560x1600 @ 60Hz

- Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz

- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)

- Supports Blu-ray Stereoscopic 3D with HDMI Port

- Supports AMD Steady Video™ 2.0: New video post processing capability for automatic jitter reduction on home/online video

Supports HDCP with DVI-D and HDMI Ports

- Supports Full HD 1080p Blu-ray (BD) playback with DVI-D and HDMI Ports

Audio

- 5.1 CH HD Audio (Realtek ALC662 Audio Codec)

Supports Surge Protection (ASRock Full Spike Protection)

LAN

- PCIE x1 Gigabit LAN 10/100/1000 Mb/s

Realtek RTL8111FR

Supports Wake-On-WAN

Supports Wake-On-LAN

Supports Lightning/ESD Protection (ASRock Full Spike Protection)

Supports LAN Cable Detection

- Supports Energy Efficient Ethernet 802.3az

Supports PXE

Expansion / Connectivity

Slots

- 1 x PCI Express 3.0 x16 Slot (PCIE1 @ x16 mode)

- 1 x PCI Express 2.0 x1 Slot

- 1 x PCI Slot

Supports AMD Dual Graphics

*PCIE 3.0 is only supported with FM2+ CPU. With FM2 CPU, it only supports PCIE 2.0.

Storage

- 6 x SATA2 3.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug

Connector

- 1 x Print Port Header

- 1 x COM Port Header

- 1 x Chassis Intrusion Header

- 1 x TPM Header

- 1 x CPU Fan Connector (4-pin)

- 1 x Chassis Fan Connector (4-pin)

- 1 x Power Fan Connector (3-pin)

- 1 x 24 pin ATX Power Connector

- 1 x 4 pin 12V Power Connector

- 1 x Front Panel Audio Connector

- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))

Rear Panel I/O

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x D-Sub Port

- 1 x DVI-D Port

- 1 x HDMI Port

- 6 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)

HD Audio Jacks: Line in / Front Speaker / Microphone

Other Features / Miscellaneous

Unique Feature

ASRock A-Tuning

ASRock APP Shop

ASRock Instant Boot

ASRock Instant Flash

ASRock APP Charger

ASRock XFast LAN

ASRock XFast RAM

ASRock Crashless BIOS

ASRock OMG (Online Management Guard)

ASRock Internet Flash

ASRock UEFI Tech Service

ASRock Dehumidifier Function

ASRock Easy RAID Installer

ASRock Easy Driver Installer

ASRock Interactive UEFI

ASRock Fast Boot

ASRock x-Boost

ASRock Restart to UEFI

ASRock USB Key

ASRock FAN-Tastic Tuning

- Hybrid Booster:

ASRock U-COP

Support CD

- Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar, Start8 (30 days trial)

Accessories

- Quick Installation Guide, Support CD, I/O Shield

- 2 x SATA Data Cables

Hardware Monitor

CPU temperature sensing

Chassis temperature sensing

CPU FAN Tachometer

Chassis FAN Tachometer

CPU/Chassis Quiet FAN

CPU/Chassis FAN multi-speed control

CASE OPEN Detection

- Voltage monitoring: +12V, +5V, +3.3V, Vcore

Form Factor

Micro ATX Form Factor

All Solid Capacitor design

High Density Glass Fabric PCB

OS

- Microsoft® Windows® 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-bit / 7 32-bit / 7 64-bit

Certifications

- FCC, CE, WHQL

- ErP/EuP ready (ErP/EuP ready power supply is required)
